Belcake 670 Advanced DepositorAdvanced technology

Specially designed for cake production

Design FeaturesSpecifications

Series

  • Belcake 670 Advanced Depositor
  • Belcake 1340 Advanced Depositor


Design Features

  • volumetric stainless steel depositor, specially designed for cake production
  • depositing of batter/sponge, icing of cake middle layers, top+side finishing of cakes and decoration
  • mounted on a mobile frame, manually adjustable in height for the most ergonomical operation and to avoid repartition injuries.
  • can be fitted with optional nozzles and attachments and used as a regular depositor for depositing, layering, injection and decoration
  • an easy-to-use digital display panel; while you are adjusting the speed of the cream coming out of the nozzle (depending on its viscosity), the speed of the turntable is synchronized automatically
  • adjustable turning angle of the turntable (370°- 720°) for a cleaner and nicer result of icing
  • applications: cakes with butter cream, vegetable cream, dairy cream, mousses, custard, batter for cakes, muffins, jam, jelly, fruit fillings, etc.

Photo Gallery


Specifications

Belcake 670 Advanced DepositorBelcake 1340 Advanced Depositor
PowerAir: 121 l/min at 30 deposits/min 7 Bar / 102 PSIAir: 219 l/min at 30 deposits/min 7 Bar / 102 PSI
Electricity100-240 V, 1 Ph, 50/60 Hz, 120 W100-240 V, 1 Ph, 50/60 Hz, 120 W
Deposit speedup to 120 depositsup to 120 deposits
Icing speedup to 6 cakes/minup to 6 cakes/min
Cake diameterMax 200 mmMax 285 mm
Deposit range5-670 ml5-1340 ml
Hopper60 l60 l
Materialstainless steelstainless steel
